| FRAME | BIG.TRAIL TFS II; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
| SHOCK | |
| FORK | SR Suntour XCR34; Air; 140 STR; platform |
| BRAKE-F | Shimano MT200; 2 piston |
| BRAKE-R | Shimano MT200; 2 piston |
| ROTOR-F | Shimano RT10; 180mm |
| ROTOR-R | Shimano RT10; 180mm |
| CHAIN | KMC xGlide |
| CHAINGUARD | |
| CRANKSET | Shimano CUES U4000; 32 ATC |
| CRANK LENGTH | 170 mm for all sizes |
| BOTTOM BRACKET | FSA BB-7420ST 127.5mm |
| DERAILLEUR-FRONT | |
| DERAILLEUR-REAR | Shimano CUES U4000; |
| CASSETTE | Shimano LG300; 11-46 ATC; 9 GER |
| GRIPS | MERIDA COMP EC |
| HANDLEBAR | MERIDA COMP TR; MAT aluminium; 780 WHB; 20 RHB |
| STEM | MERIDA COMP TR; MAT aluminium; 35 DSH; 7' ASD |
| STEM SIZE | 40 mm |
| HEADSET | Acros ICR MERIDA EXTERNAL neck; Upper and lower IPS sealing |
| HUB-F | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB-R | Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
| AXLE-F | |
| AXLE-R | MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| RIM | MERIDA COMP CC II; 25 IWR; MAT aluminium; tubeless ready |
| SADDLE | MERIDA COMP SL; 25% recycled material; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEATPOST | MERIDA COMP TR II; 34.9 DSP; 0 SSB; XS: 150 SPT，S: 170 SPT，M/L: 200 SPT，XL: 230 SPT |
| SHIFTER-FRONT | |
| SHIFTER-REAR | Shimano CUES U4000 |
| SPOKES | Black stainless |
| TIRE-F | Kenda Regolith; 29x2.4"; wire |
| TIRE-R | Kenda Regolith; 29x2.4"; wire |
